CS8959 EVB - Product Image
Description
The CS8959 EVB is an evaluation board specifically designed for applications in automotive electronics, including CAN 2.0 Bus technology, an in-vehicle serial communication network controller that can effectively enable distributed control and real-time monitoring. The CS8959 EVB has two CAN buses that can be used for automotive body control units and gateway control units.
Key Features
- MCU: MysonCentury CS8959
- 2 CAN Port: Microchip MCP2551 (Including 120Ω Terminal Resistor)
- 2 RS-232 Port (Male x1 & Female x1)
- 4x4 Matrix keyboard, ADC, EEPROM, 5x7 LED, 4-bit Seven-segment display, LED x2 (Monochrome LED & Full color LED), Text type LCD, 8-bit DIP switch, Buzzer, Infrared receiver, Temperature sensor (DS18B20)
- Power supply via USB interface
